KC IEC62133 CB CE Approve 523048 3.7v li polymer battery 3.7v 1000mAh

Inquiry Now

Product Details

Items	Parameter
Battery model	DTP523048
Nominal voltage	3.7V
Minimum capacity	1000mAh(0.2C discharge)
Charging voltage	4.2V
Discharging cut-off voltage	3.0V
Standard charging	0.2C /4.2V
Max charging	1.0C /4.2V
Standard discharging	0.2C/3.0V
Max discharging	continuous discharge	1.0C/3.0V
	non-continuous discharge	2.0C/3.0V
Shipment voltage	≥3.85V
Battery pack impedance	≤110mΩ
Operating temperature	Charging: 0°C ~ 45°C
	Discharging: -20°C ~60°C
Storage (At 50% SOC and specified temp, recoverable capacity in % vs time )	-10℃~25℃	(12 months ≥85% )
	-10℃ ~45℃	(6 months ≥85% )
	-10℃~55℃	(1 month ≥90% )
	20±5℃ is the recommended storage temperature
Visual Inspection	There should not be any remarkable scratches, cracks, bolts, cauterization, deformations, swelling, leakage and so on the surface of the cell.
Reference standard	GB/T 18287-2013,KC CE ROHS IEC/EN61960, UL164

BATTERY PARAMETERS

Model:DTP523048

Max dimension:5.2*30*48（mm).

Customizable PCM and connector, Wire length

Get certificate：KC CB CE ROHS UL UN38.3 BIS

Discharge cut-off voltage: 2.75V

Maximum charging voltage: 4.2V

Continuous work current:200mA(0.2C)

Maximum charge current:500mA(0.5C）1C Can be customized

Working temperature (discharge):-10℃-60℃

Working temperature (charging):0℃-45℃

APPLICATION

1) Electronic cigarette

2) Bluetooth device

3) MP3/MP4

4) GPS tracker

5) Smart wearable equipment

6) Beauty Instrument

7）DVD paly

OUR ADVANTAGE:

1) 12 Years + experience in lithium battery production and research and development;

2) 25 A level lithium battery R&D engineers;

3) We pay more attention to environmental protection and safety performance of lithium batteries, all products meet ROHS standards, safe and non-explosive;

4) We pay more attention to product quality and customer service. After we receive the consultation at any time, we will reply to our customers within 48 hours.
