3.7v 650mAh Li polymer battery 601574 with protection circuit and wires 30mm Model:DTP601574 Maxn dimension:6.0*15*74（mm).Customizable PCM and connector, Wire length Get certificate：KC CB CE ROHS UL UN38.3 BIS

3.7v 650mAh Li polymer battery 601574 with protection circuit and wires 30mm

Model:DTP601574
Voltage:3.7V
Capacity:650mAh

Inquiry Now

Product Details

Items	Parameter
Battery model	DTP601574
Nominal voltage	3.7V
Minimum capacity	650mAh(0.2C discharge)
Charging voltage	4.2V
Discharging cut-off voltage	3.0V
Standard charging	0.2C /4.2V
Max charging	1.0C /4.2V
Standard discharging	0.2C/3.0V
Max discharging	continuous discharge	1.0C/3.0V
	non-continuous discharge	2.0C/3.0V
Shipment voltage	≥3.85V
Battery pack impedance	≤80mΩ
Operating temperature	Charging: 0°C ~ 45°C
	Discharging: -20°C ~60°C
Storage (At 50% SOC and specified temp, recoverable capacity in % vs time )	-10℃~25℃	(12 months ≥85% )
	-10℃ ~45℃	(6 months ≥85% )
	-10℃~55℃	(1 month ≥90% )
	20±5℃ is the recommended storage temperature
Visual Inspection	There should not be any remarkable scratches, cracks, bolts, cauterization, deformations, swelling, leakage and so on the surface of the cell.
Reference standard	GB/T 18287-2013,KC CE ROHS IEC/EN61960, UL164

BATTERY PARAMETERS

Model:DTP601574

Max dimension:6.0*15*74（mm).

Customizable PCM and connector, Wire length

Get certificate：KC CB CE ROHS UL UN38.3 BIS

Discharge cut-off voltage: 2.75V

Maximum charging voltage: 4.2V

Continuous work current:130Am(0.2C)

Maximum charge current:325mA(0.5C）1C Can be customized

Working temperature (discharge):-10℃-60℃

Working temperature (charging):0℃-45℃

APPLICATION

1) Electronic cigarette

2) Bluetooth device

3) MP3/MP4

4) GPS tracker

5) Smart wearable equipment
